SGD-04AN - Servopack - YASKAWA
This YASKAWA servo drive has the reference SGD-04AN. It corresponds to the range of YASKAWA servo drives Σ-Series Servomotor SGM/SGD.
Servo drive: Input: 200-230V, 3 PH, 50 / 60Hz, Output: 0-230V, 1PH, 8A, 400W.
YASKAWA servo drive reconditioned and tested on a manufacturer's test bench (100% test).
- The highest available power rates and response in this class of servo.
- Compared with conventional products, these servomotors are approximately 1/3 both in volume and weight and SERVOPACKS are approximately 1/4 in volume.
- The book-shapeSERVOPACKScan be used with either incremental encoders or absolute encoders.
- Positioning is performed using the MECHATROLINK High-speed Field Network.
- Electronic gear function provided.
- For incremental encoders, there are now only 9 lines to wire between the encoder and the SERVOPACK (previously: 15 lines).
- There are now only 6 I/O points to wire (previously: 15 I/O points).
- Improved environmental resistance by using varnish coating.
- Improved dispersion with command cable length up to 50 m (previously: 3 m).
The SERVOPACK has a built-in overload protective function to protect the SERVOPACK and Servomotor from overload. Allowable power for the SERVOPACK is therefore limited by the overload protective function.
The overload detection level quoted under hot start conditions at a motor ambient temperature of 40°C cannot be modified.
Yaskawa The company was founded in 1915 and its headquarters is located in Kitakyushu, Japan.
The company is the world leading manufacturer of servo motors, converters, axis drives and control systems used in industrial automation, and Motoman robots.
