A06B-6079-H207

This FANUC 2-axis and reference A06B-6079-H207 is available to replace your equipment. SVM2-40/80

Input: 283-325V, Output: 8.5 kW, Output 230v ~ 12.5A / 18.7A

This A06B-6079-H207 drive is at your disposal to replace your defective hardware and has a warranty adapted to your needs.

Module reconditioned and tested under full load (duration test) on FANUC bench.

In stock, ready to ship.
State
  • Refurbished Service Exchange
  • Refurbished Supply
Warranty
€2,100.00
VAT excluded

System options

Exchange service with a refurbished unit

Standard Exchange Service

Reconditioned and tested systems

From 6 to 12
month warranty

Exchange service with a new unit

Standard Exchange Service

New systems

From 12 to 24
month warranty

Supply of a refurbished unit

Supply Service

Reconditioned and tested systems

From 6 to 12
month warranty

Supply of a new unit

Supply Service

New systems

From 12 to 24
month warranty

For parts only

Supply Service

Sold for parts – no warranty

Repair

Repair service

Repair will be made to damaged and defectiv units

From 3 to 18
month warranty

Livraison rapide

Fast
delivery

Livraison rapide

guaranteed
products

Livraison rapide

Secure
payment



The alpha series SERVO AMPLIFIER MODULE with FSSB is used with the new optical interface FSSB.
The specifications of this SVM is same that of the current SVM except for the interface.
The interchangeable current SVM and SVM for FSSB have ident ica I model names in the drawing numbers. The middle nibbles of the drawing number, however, are different : 6079 for the current SVM and 6096 for SVM with FSSB.

Connect the optical

- Connect the optical cable from COP10A on CNC to COP10B on the first AMP.

- The optical cables from COPlOA of the previous AMP is connected to COP10B of the next AMP.

- Please put the attached cap on COP10A of the last AMP to protect the optical connector form dust.

- Up to 8 axes are available. (The number of the axes is not the number of the AMPs.

Applicable CNC

FANUC Series 30i/300is/300i, FANUC Series 31i/310is/310i A5, FANUC Series 31i/310is/310i, FANUC Series 31i/310is/310i, FANUC Series 32i/320is/320i.

Number of controlled axes

- Series 30i/300is/300i : 32 maximum

- Series 31i/310is/310i A5 : 20 maximum

- Series 31i/310is/310i : 20 maximum

- Series 32i/320is/320i : 9 maximum

Number of spindle controlled axes

- Series 30i/300is/300i : 8 maximum

- Series 31i/310is/310i A5 : 6 maximum

- Series 31i/310is/310i : 6 maximum

- Series 32i/320is/320i : 2 maximum

Amplifier

- α series servo amplifier, α series spindle amplifier, α series power supply module, αi series servo amplifier, βi series servo amplifier, αi series spindle amplifier, αi series spindle amplifier

Motor

- α series servo motor

- α series spindle motor

- β series servo motor

- αi series servo motor

- αi series spindle motor

- αis series servo motor

- βis series servo motor

- Lis series linear motor

I/O

- I/O unit (I/O Link)

Software

- Dual check safety software option

DETECTOR SYSTEM

The detectors below can be used.

Feed axis detector

-Pulsecoder αA1000, αA64,

- αA16000i, αA1000i, αI1000i, αA64i

- βA64B, βA32B

- βI64B, βI32B

- Separate type detector (A quard B)

Spindle detector

- M sensor, MZ sensor, BZ sensor, Mi sensor, MZi sensor, MZi sensor, BZi sensor, CZi sensor.

High Resolution Serial output circuit

Height
38 cm / 14,9 in
Width
9 cm / 3,5 in
Length
30,7 cm / 12,09 in
Weight
4,5 kg / 9,9 lbs
Family
FANUC ALPHA SERVO MODULE
Reference
A06B-6079-H207
Refurbished
3003506750902
300465370213

FANUC is a Japanese manufacturer of industrial robots, machining centers and numerical controls for machine tools

Since its creation in 1956, when the company’s founder, Dr. Seiuemon Inaba, introduced the concept of digital controls, FANUC has always been at the forefront of manufacturing techniques in the world. Moving from the automation of a single machine in the late 1950s to the automation of entire production lines over the following decades.
