4PP065.0351-X74 - Panel - B&R
This B&R touch panel reference 4PP065.0351-X74 is part of the POWER PANEL 65, PP65 range.
Power Panel PP65, 3.5" QVGA color TFT display with touch screen (resistive), 30 function keys, 128 MB DRAM, 232 kB SRAM, CompactFlash slot, 1x ETH 10/100, 1x X2X Link, 2x USB, IP65 protection
This B&R terminal is at your disposal to replace your defective equipment and has a guarantee adapted to your needs.
Device 100% tested.
System Features
The PP65 is a particularly compact addition to the proven Power Panel product family. Modular fieldbus interfaces ensure flexible integration into all configurations. Ethernet, POWERLINK and X2X Link are used for the communication system. In addition, these devices have been equipped with a slot for interface modules. Depending on requirements, the Power Panel 65 can be expanded with CAN bus, a PROFIBUS DP slave or an RS485/RS232 interface, which makes it ideal for tasks. Custom panel overlay designs are also available.
• Cost effective complete solution
• Compact dimensions
• Integrates controller, visualization and I/O interface
Compact solution
The PP65 is both a controller and an operator panel. All necessary peripherals can be connected using the integrated X2X interface. Thanks to the optional interface modules, it is also possible to connect other B&R products or even to integrate the PP65 into control systems from other manufacturers. All components are located in a compact housing with a 3.5" or 5.7" QVGA TFT display.
Simple programming
The full integration of the HMI application into B&R's Automation Studio programming and diagnostic tool goes without saying. The same applies to programming in all IEC languages offered by B&R as well as Automation Basic and ANSI C.
An ideal solution for multi-axis applications
The PP65 is particularly suitable for multi-axis applications requiring high computing power but with limited cabinet space.
The PP65 is equipped with a powerful Geode LX800 500 MHz processor. With this processing capability, the PP65 delivers performance that previously was only achievable with the PP400. The PP65 is particularly well suited for multi-axis applications that require high processing power but where space in the electrical cabinet is limited.
High flexibility thanks to screen and interfaces
The PP65 is available with two different types of screens with identical installation dimensions: a 5.7" model with touch screen (without function keys) and a 3.5" model with touch screen and 30 function keys . The PP65 is additionally equipped with two USB ports and a Fast Ethernet port for exchanging data with higher-level systems. The PP65 is available with optional integrated X2X or POWERLINK interfaces for connecting remote I/Os and drives. The devices can be supplemented with RS2332/RS485, CAN and PROFIBUS DP slave interfaces depending on requirements.
B&R is an Austrian company founded in 1979 by Erwin Bernecker and Josef Rainer in Eggelsberg near Salzburg.
B&R provides complete solutions in industrial automation.
Range of extended products programmed and configured using Automation Studio software.
