XBT GT2130 - HMI - TELEMECANIQUE
This terminal XBT GT2130 and brand TELEMECANIQUE is a terminal of the Magelis range.
Backlit Colour STN LCD, VGA resolution, monochrome, STN LCD, Ethernet port .
This XBT GT2130 Telemecanique terminal is at your disposal to replace your defective equipment and has a guarantee adapted to your needs.
The screens in the XBT GT range are cULus certified and CSA certified.
These units have been developed to comply with the following standards:
- UL 508: industrial control equipment
- UL 1604: electrical equipment for use in Class I and II, Division 2 and Class III hazardous locations
- UL 60950: Information Technology Equipment Security Standard
- CAN / CSA-C22.2, No. 14, No. 213 and No. 60950 various industrial control equipment in hazardous locations.
Connect the power cord to the power connector on the side of the XBT GT unit via the power plug.
Make sure to use a Class 2 stabilized power supply to connect the line to ground.
To improve noise resistance, twist the ends of the power cord wires before connecting them to the power outlet.
The power cord of the XBT GT unit must not be attached with the main circuit lines (high current and voltage) or the input and output signal lines. It should not be located near these lines either.
Connect a surge protector to handle surges.
Minimize the length of the power cord to reduce noise.
Since its creation, the Telemecanique brand has been pursuing an innovation policy, which has become one of the world’s first references in automatism management.
The story of Telemécanique is read through that of its inventions, initiated with the launch of the first contactor on bars. A patent filed the same year of its acquisition, in 1924! It will develop contactors D became world reference. The 1980s marked the acquisition of Telemechanics by Schneider Electric (1988).
